Technical performance and parameter HRM2200M vertical mill(coal)

Technical performance and parameter HRM2200M  vertical mill
(One),main technical parameter
Specification:               HRM2200M
Diameter of mill table:       φ2200
Diameter of mill roller:       φ1500mm
Number of mill roller:        2pcs
Mill table speed:            34.2r/min
Max feeding size:           25mm
Mill feeding moisture:        ≤10%
Product fineness:            ≥  cm²/g
Capacity:                  40~45t/h((200meshs)≥80% getting across
Protect moisture:            ≤1.0%
Mill air feeding temperature:   <350 °C
               Mill air discharging temperature:  80~90°C
               Mill discharging air flow: 125000m³/h
Mill pressure drop:          4000~6000Pa
Working pressure of hydraulic system:≤8-14MPa
Mill dimension:    Length:   mm
                           Width:    mm
                           Height:   mm
Total weight of mill:               330000kg
(two),Main motor
Type:                     YRKK560-6
Power:                     560KW
Speed:                     990r/min
Voltage:                     10KV
Protection grade:              TP54
(three),Main reducer
Manufacturer:Nanjing High Accurate Drive Equipment Manufacturing Group Co., Ltd
Type:MLX60-F
Qty:1pc
(four),high-low lubrication oil station and auxiliary oil tank
Model:XGD30/250
(five),separator
Rotor speed:                 50~200r/min
Motor type:                 YVP280S-4
Motor power:                 75KW
Reducer type:               RV202-6.3IAR
(six),Hydraulic system
TOTAL WEIGHT 128300KG
