Technical text of PFG180-120 type rolling machine

一、Technical parameter

1Equipment name: PFG180-120type rolling machine

2Usage: it is used for grinding cement clinker

3Amount: One unit

4Material name: Cement clinker and so on

5integrated moisture: 11.5%

6Feed size: 80mmoccupied 5%

7Discharging size: 2mmoccupied above 60%

8Production capacity     650800 t/h,  Average  650800 t    Maximum          800      t/h

9Working system       Continuous

10Power supply method     Voltage 10000V

       YRKK630-6        motor model YRKK630-6

11Arranging method    Indoor

12Required power     2x1250 kW

13Roller diameter          1800mm

14Roller width              1200mm

15Roller rotary speed    18.5 r/min

16Equipment weight        235.0 t

17 Manufacturer       Jiangsu Pengfei Group Co., Ltd

二、 Scope of supply and specification of main components and parts

Scope of supply

1Main machine: includes frame of bearing series, feeding device, torque support, hydraulic system, lubricating system

2Main drive part: includes motor, reducer, coupling, and base;

3 Others: includes motor start-up cabinet, foundation bolts, cooling device, electrode for wear-resisting repair welding 10kg, special tools along with the equipments. The detailed scope of supply is based on the general drawings (drawing no) and unit assembly drawings supplied by Jiangsu Pengfei Group Co.,Ltd , every unit mainly includes:

1Main frame

2Main shaft

3Bearing base

4Main bearing

5Reducer

6Main motor

7Cardan joint driving shaft

8Motor base

9Hydraulic system

10Foundation bolts

11Automatic grease lubricating system (including electric filling pump)

Technical documents and time supplied by the supplier

 1. General assembly drawing              two sets

 2. Operating instruction manual          one set

 3. Packing list                          one set

 4. In the above documents the first item is supplied to the buyer after signing the contract within one week and it is in duplicate, others will be supplied to the buyer when deliver the goods.





V type scatter classifier text

1、. Technical parameter

1Equipment name    PFV4000 type classifier

2Usage            It is used for scattering and classifying the separating, extrusion materials

3Amount           One unit

4Material name    Fresh material and extrusion materials

5Integrated moisture  11.5%

6Feed size          Dmax30mm

7Discharge size   0.5mm

8Production capacity    Average 800950 t/h

9Working system   Continuous

10Arranging method   Indoor

11Equipment weight    40t

12Manufacturer    Jiangsu Pengfei Group Co., Ltd

II. Scope of supply and specification of main components and parts

   Scope of supply: Shell, shell liners, diaphragm for scattering. The detailed scope of supply is based on the general drawing (Drawing no) and unit general drawing supplied by Pengfei Group.

   Every unit main include:

   1. Shell

   2. Shell liners and diaphragm for scattering

III. Technical documents and times supplied by the supplier

     1. General assembly drawing for V type classifier     one set

     2. Packing list                                       one set

     In the above documents the first item is supplied to the buyer after signing the contract within one week and it is in duplicate, others will be supplied to the buyer when deliver the goods.

=========================================================================================================
