Description of Vertical Coal Mill:
This vertical coal mill is typically designed to process materials in medium hardness, like soft coal or bituminous coal, and it is mainly used in positive pressure pulverizing system of soft coal. It is widely used in electricity field, metallurgy sector, building material industry, chemical industry, and so on.
It has features of low energy consumption, small occupation area, easy operation, low noises, reliable performance, big crushing ratio, long-lifespan grinding components, strong applicability, and so on.
Technical Parameters of Vertical Coal Mill:
| Name | Unit | HRM1300M | HRM1400M | HRM1500M | HRM1700M | HRM1900M | |
| Grinding disc diameter | mm | Φ1300 | Φ1400 | Φ1500 | Φ1700 | Φ1900 | |
| Output | T/H | 10-15 | 12-17 | 16-22 | 20-28 | 26-35 | |
| Feeding | MM | 0-40 | 0-40 | 0-45 | 0-50 | 0-55 | |
| Feeding moisture | % | <15 | <15 | <15 | <15 | <15 | |
| Product fineness | % | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 | |
| Product moisture | % | <1 | <1 | <1 | <1 | <1 | |
| Power of main motor | KW | 200 | 200 | 280 | 315 | 400 | |
| Feeding temperature of air | ℃ | <450 | <450 | <450 | <450 | <450 | |
| Discharging temperature of air | ℃ | 80-95 | 80-95 | 80-95 | 80-95 | 80-95 | |
| Air discharging volume | M3/H | ~40000 | ~45000 | 65000 | 80000 | 100000 | |
| Weight | T | 45 | 52 | 75 | 96 | 100 | |
